1. Powerful Engine Performance: Our rice transplanter is equipped with a high powered engine that provides sufficient energy to operate efficiently, even in deep puddled fields. The engine is designed to maintain a stable RPM, ensuring that the machine can work continuously without any power drop. This powerful performance allows the transplanter to handle tough field conditions and complete the transplanting task in a timely manner.
2. Gentle Seedling Transplanting Mechanism: The transplanter features an innovative R fork and push rod planting mechanism. This mechanism is designed to handle seedlings with the utmost care, gently transplanting them into the ground without causing any damage. The presence of the R fork in addition to the push rod makes it easy to maintain and replace the wearable parts, ensuring the long term reliability of the machine.
3. Superior Traction and Mobility: The rice transplanter is fitted with long life lugged rubber wheels. These wheels provide excellent traction during the transplanting process, allowing the machine to move smoothly through wet and muddy fields. In addition, the wheels make it easy for the transplanter to move between different fields and on roads, increasing its overall mobility and versatility.
4. Customizable Seedling Feed Adjustment: We understand that different rice varieties and farming requirements call for different numbers of seedlings per hill. Our rice transplanter comes with a seedling feed adjustment feature that allows farmers to select and automatically adjust the number of seedlings per hill. This customization ensures efficient transplanting, preventing any wastage of seedlings and promoting optimal growth of the rice plants.
5. Advanced Hydraulic System: The machine is equipped with an effective hydraulic and auto hydraulic system. This system ensures a uniform planting depth, regardless of whether the soil is hard or soft. It also has the ability to automatically adjust the height of the machine in case of obstacles during transplanting. This not only prevents accidents but also protects the machine from damage, ensuring its long term durability.
1. Commercial Rice Plantations in Tropical Regions: In tropical regions, where the climate is favorable for rice cultivation throughout the year, commercial rice plantations require high volume and efficient transplanting solutions. Our rice transplanter's powerful engine, multi row planting capability, and adjustable seedling feed make it an ideal choice for these large scale operations. It can handle the continuous and intensive transplanting work required in tropical commercial rice farms, helping farmers maximize their yields.
2. Rice Farms in Hilly and Mountainous Areas: Hilly and mountainous areas often pose challenges for agricultural machinery due to the uneven terrain. However, our rice transplanter's excellent traction, high ground clearance, and adaptable hydraulic system make it suitable for such areas. The machine can navigate through the slopes and uneven ground, planting seedlings at the correct depth and spacing, thus enabling farmers in hilly regions to improve their rice cultivation efficiency.
3. Contract Farming Operations: For contract farming operations, where farmers are often required to meet specific quality and quantity targets, our high performance rice transplanter is a valuable asset. The precise transplanting, customizable seedling feed, and reliable performance of the machine ensure that the rice crop meets the required standards. It also helps contract farmers complete their planting tasks on time, fulfilling their contractual obligations effectively.
Specification and model | 2ZSQ-4 | 2ZSQ-6 | ||
structural style | Hand held style | |||
External dimensions | Length(mm) | 2140 | 2390 | |
Width(mm)（working） | 1630 | 1960[2280] | ||
High(mm) | 940 | |||
structural quality(kg) | 162 | 190 | ||
Engine | Model name | PW175、JL175-FE、SPE175、GT175、MZ175 | ||
type | Air cooled 4-stroke OHV engine | |||
Displacement(L(cc)) | 0.171（171） | |||
Output power/speed(kW/r/min） | 3.3/3600 | |||
fuel | Standard gasoline for automobiles (unleaded) | |||
Fuel tank capacity(L) | 10.0 | |||
Ignition method | Contactless electromagnetic ignition | |||
Start mode | Hand pulled/electric start | |||
Fuel Consumption（kg/hm2） | 2.0～3.5 | 2.0～4.5 | ||
Driving Department | Wheel adjustment | Hydraulic (up and down) | ||
Traveling wheel | structural style | Coarse wheel hub rubber tire | ||
Diameter(mm) | Φ660 | |||
Variable speed mode | Gear coupling transmission | |||
Variable speed series (stages) | Advance by 2 levels (transplanting by 1 level) • Retreat by 1 level | |||
Transplanting Department | Insertion arm type | Crank rocker type | ||
Transplant rows (rows) | 4 | 6 | ||
Transplanting row spacing(cm) | 30 | |||
Transplanted plant spacing(cm) | 12•14•16•18•21 | |||
Type of plant spacing adjustment mechanism | Replace the gear and adjust the handle | |||
Number of plant spacing adjustment gears | 5gear | |||
Planting depth(cm) | 0.7～3.7（9级） | |||
Migration distance and seedling depth(mm) | Standard configuration 15.5 (optional 20, 17.5), seedling depth 7-17mm (level 9) | |||
operating speed（m/s） | 0.34～0.77 | 0.28～0.77 | ||
Walking speed on the road（m/s） | 0.58～1.48 | |||
Hourly productivity of homework（h㎡/h） | 0.091～0.18 | 0.1～0.3 | ||
Seedling conditions | Types of seedlings | Padded seedlings | ||
1. Powerful Engine Performance: Our rice transplanter is equipped with a high powered engine that provides sufficient energy to operate efficiently, even in deep puddled fields. The engine is designed to maintain a stable RPM, ensuring that the machine can work continuously without any power drop. This powerful performance allows the transplanter to handle tough field conditions and complete the transplanting task in a timely manner.
2. Gentle Seedling Transplanting Mechanism: The transplanter features an innovative R fork and push rod planting mechanism. This mechanism is designed to handle seedlings with the utmost care, gently transplanting them into the ground without causing any damage. The presence of the R fork in addition to the push rod makes it easy to maintain and replace the wearable parts, ensuring the long term reliability of the machine.
3. Superior Traction and Mobility: The rice transplanter is fitted with long life lugged rubber wheels. These wheels provide excellent traction during the transplanting process, allowing the machine to move smoothly through wet and muddy fields. In addition, the wheels make it easy for the transplanter to move between different fields and on roads, increasing its overall mobility and versatility.
4. Customizable Seedling Feed Adjustment: We understand that different rice varieties and farming requirements call for different numbers of seedlings per hill. Our rice transplanter comes with a seedling feed adjustment feature that allows farmers to select and automatically adjust the number of seedlings per hill. This customization ensures efficient transplanting, preventing any wastage of seedlings and promoting optimal growth of the rice plants.
5. Advanced Hydraulic System: The machine is equipped with an effective hydraulic and auto hydraulic system. This system ensures a uniform planting depth, regardless of whether the soil is hard or soft. It also has the ability to automatically adjust the height of the machine in case of obstacles during transplanting. This not only prevents accidents but also protects the machine from damage, ensuring its long term durability.
1. Commercial Rice Plantations in Tropical Regions: In tropical regions, where the climate is favorable for rice cultivation throughout the year, commercial rice plantations require high volume and efficient transplanting solutions. Our rice transplanter's powerful engine, multi row planting capability, and adjustable seedling feed make it an ideal choice for these large scale operations. It can handle the continuous and intensive transplanting work required in tropical commercial rice farms, helping farmers maximize their yields.
2. Rice Farms in Hilly and Mountainous Areas: Hilly and mountainous areas often pose challenges for agricultural machinery due to the uneven terrain. However, our rice transplanter's excellent traction, high ground clearance, and adaptable hydraulic system make it suitable for such areas. The machine can navigate through the slopes and uneven ground, planting seedlings at the correct depth and spacing, thus enabling farmers in hilly regions to improve their rice cultivation efficiency.
3. Contract Farming Operations: For contract farming operations, where farmers are often required to meet specific quality and quantity targets, our high performance rice transplanter is a valuable asset. The precise transplanting, customizable seedling feed, and reliable performance of the machine ensure that the rice crop meets the required standards. It also helps contract farmers complete their planting tasks on time, fulfilling their contractual obligations effectively.
Specification and model | 2ZSQ-4 | 2ZSQ-6 | ||
structural style | Hand held style | |||
External dimensions | Length(mm) | 2140 | 2390 | |
Width(mm)（working） | 1630 | 1960[2280] | ||
High(mm) | 940 | |||
structural quality(kg) | 162 | 190 | ||
Engine | Model name | PW175、JL175-FE、SPE175、GT175、MZ175 | ||
type | Air cooled 4-stroke OHV engine | |||
Displacement(L(cc)) | 0.171（171） | |||
Output power/speed(kW/r/min） | 3.3/3600 | |||
fuel | Standard gasoline for automobiles (unleaded) | |||
Fuel tank capacity(L) | 10.0 | |||
Ignition method | Contactless electromagnetic ignition | |||
Start mode | Hand pulled/electric start | |||
Fuel Consumption（kg/hm2） | 2.0～3.5 | 2.0～4.5 | ||
Driving Department | Wheel adjustment | Hydraulic (up and down) | ||
Traveling wheel | structural style | Coarse wheel hub rubber tire | ||
Diameter(mm) | Φ660 | |||
Variable speed mode | Gear coupling transmission | |||
Variable speed series (stages) | Advance by 2 levels (transplanting by 1 level) • Retreat by 1 level | |||
Transplanting Department | Insertion arm type | Crank rocker type | ||
Transplant rows (rows) | 4 | 6 | ||
Transplanting row spacing(cm) | 30 | |||
Transplanted plant spacing(cm) | 12•14•16•18•21 | |||
Type of plant spacing adjustment mechanism | Replace the gear and adjust the handle | |||
Number of plant spacing adjustment gears | 5gear | |||
Planting depth(cm) | 0.7～3.7（9级） | |||
Migration distance and seedling depth(mm) | Standard configuration 15.5 (optional 20, 17.5), seedling depth 7-17mm (level 9) | |||
operating speed（m/s） | 0.34～0.77 | 0.28～0.77 | ||
Walking speed on the road（m/s） | 0.58～1.48 | |||
Hourly productivity of homework（h㎡/h） | 0.091～0.18 | 0.1～0.3 | ||
Seedling conditions | Types of seedlings | Padded seedlings | ||
